Factory-assembled with all components:
- Housing (volute & cover)
- Impeller
- Seal
About Frame Size:
Through-bolt spacing on a 48 frame motor will be less than 4 inches. A 56 frame
motor's bolts will be spaced more than 4 inches apart.
|
|
|
How to Determine Spa Pump Plumbing Size
|
|
Pump plumbing sizes are nominal, and not actual outside diameter (OD) of the threaded
intake or discharge. Use a tape measure and check your old pump thread size against
this sizing table for most* spa pump brands:
|
|
Plumbing Size
|
|
Pump Thread O.D. (approx.)
|
|
| 1.5"
|
|
2-3/8"
|
|
| 2.0"
|
|
3"
|
|
| 2.5"
|
|
3-5/8"
|
|
Some brands of hot tub spa pumps (such as Hayward, Jacuzzi, and Sta-Rite) use non-standard
fittings with different dimensions. Please contact our Parts Help desk if you need
assistance with these.
